2. Turnstile offer a compact, cost-effective, fast operating, easy to use, reliable entrance solution for internal or external use in areas where there is a large and constant flow of people.
The advantages of using a turnstile compared to a conventional gate include the better utilization of manpower, increased reliability and improved security.
Function Parameters:
| Thickness: | 1400 * 180 * 1020mm |
| Work Voltage: | AC110~220V±10V |
| Working Environment Temperature: | -35℃～75℃ |
| Drive motor: | DC motor 24V |
| Communication Interface: | RS232/RS485 serial port |
| Communication Protocol: | MODBUS protocol |
| Working Speed of the Gate: | ≤30 persons/min |
| Swipe pass time: | 10s |
| Channel width | ≤1000MM |
Packing & Delivery:
| Measurement | Total G.W. |
| 1600*300*1040MM | 80.00KG |
Basic Functions:
●Alarm Function: Sound and light alarm function.
●Anti-interference: To prevent the gate abnormal caused by electromagnetic and other external causes.
●Passage Mode Setting: Unidirectional passage, bidirectional passage and free passage can be set through the main control board keys.
●Anti-tailgating: To prevent the unpermitted situation of passing too many people at once.
● Anti-clamp Function: When the brake is in the process of closing, the brake will stop closing after detecting the anti-clamp signal.
●Self-reset. Pass right will be canceled if people do not go through within a set time, the default time is 10s, and the passage time can be set by switch.
●Access Control: The external port can be connected to a variety of biometric identification devices.
●The gate opens after power failure.
●Fault Detection: The control board can support fault type detection, fault cause analysis, and fault troubleshooting.
●Passing Indicator: Traffic status indicator light; the alarm function of overstay time in the channel can be set.
FAQ:
Q: How will the products be packaged for export?
A: Our products are packaged in wooden crates with pearl cotton and cling film for export transportation.
Q:What kind of shipping method do you use for the products?
A: Our company has opened three kinds of transportation channels by sea, land and air, the products can be given to you in the best way.
Q: Does the product arrive in my country with or without taxes?
A: It depends on the country and the shipping way you choose. Most Asian countries, most European countries, the United States, and Canada have tax-included shipping channels if needed.
Q:How to ensure after-sales service?
A: You can find our sales staff at any time. If you encounter any technical problems,welcome to contact with us to have a face time to solve it.
Q: If we could be your agent or distributor?
A: Please talk with our sales for this, our company are warmly welcome more partner to join us, but you have to double check for some area we have agents already.
8. Driving current: ＞ 200mA;
9. Communication interface: RS485 electrical standard;
10. Communication distance: ≤ 1200m;
11. Maximum channel width: 800-1000mm;
